Radion wireless motion detector RFDL-11 from Bosch provides the range, scalability and exceptional battery life required to ensure reliable performance and superior quality from a wireless detector.

Advanced diagnostics and multiple device enrollment options make installation and maintenance simple and cost effective.

With a complete line of peripherals, RADION provides the flexibility for virtually any application requirement.

Model: RFDL-11

We recommend using this Detector if you have pets or the detector is going into a hot environment like a Garage

Features

• 11m x 11m (35 ft by 35 ft) coverage
• Up to 45Kg (100 lb.) Pet Immunity
• Flexible Mounting Height
• Compatible with Bosch premises wireless systems
• Draft and Insect immune
• Motion Analyzer II Signal Processing
• Supervised for low-battery, cover-tamper, and removal from mounting surface tamper conditions.
• Operational up to 5 years using 4 user replaceable AA Alkaline Batteries
• Pet Immunity: The detector is able to distinguish between signals caused by humans and signals caused by pets such as a dog up to 45kg (100lb) or two dogs at 27kg (60lb) or up to ten cats. This provides immunity to false alarms while maintaining proper catch performance of human targets.
• Draft and Insect Immunity: The sealed optical chamber provides immunity to drafts and insects.
• Temperature Compensation: The sensor adjusts its sensitivity maintain consistent catch performance at critical temperatures.
• Battery Life Extension feature (PIR and TriTech): In the normal operating mode, an alarm can be transmitted only after three (3) minutes have passed since the previous alarm restoral. This 3 minute lockout time reduces unnecessary RF transmissions in high traffic areas, thereby extending battery life.

Compatible Alarm Systems

• RF3212E Receiver
• Radion SD12 bus compatible receiver
• Solution Ultima 880
• Solution 16i
• Solution 16Plus
• Solution 64
• Solution 144
• Solution 6000
• Bosch Solution 3000

Specifications

Dimensions:	138 mm x 72 mm x 64 mm (5.5 in x 2.8 in x 2.5 in)
Internal Coverage Point ability:	Vertical: -4? to -10?
Alarm Indicator	Blue LED for TriTech alarms Green LED for microwave detection Red LED for PIR detection
Sensitivity Selection:	Field selectable for standard or intermediate sensitivity.
Power/Voltage:	Four AA Alkaline batteries, 1.5 VDC (1.5 VDC x 4 batteries = 6 VDC total)
Battery life:	Up to 5 years
Temperature:	Functional range: -10?C to +49?(+14?F to +120?F)UL only: 0?C to +49?C (+32?F to+120?F)EN 50130-5 Class II only: -10?C to 40?C (+14?F to +104?F
Environment	Complies with EN50130-5 Class II
Relative Humidity:	Up to 93% non-condensing
Cove rand Wall Tamper Switch:	Transmits a tamper switch signal when the unit is removed from its base, or the mounting surface.
Frequency:	433.42 MHz
Use:	Intended for indoor use.
Receivers:	B810 wireless receiver (compatible with RFDL-11-A only)RFRC-OPT wireless receiver (compatible with RFDL-11 only)RFRC-OPT-CHI wireless receiver (compatible with RFDL-11-CHI only)
