The DS-PM1-O1L-WB relay module with small case design, which can be put into hiding places easily automation operating, one button turn on/off from APP/Keyfob/Keypad.

Model: DS-PM1-O1L-WB

Features

• 433MHz two-way wireless communication
• AES-128 encryption
• LED display, show status of device and replay on/off display
• Small case design, which can be put into hiding places easily
• Automation operating, one button turn on/off from APP/Keyfob/Keypad
• Setting scenarios by different events
• With one tamper input, can be used as zone input for alarm

Specifications

• Learning Button1, For register
• Scenario Setting By Alarm, By Operation, By Fault, By Schedule, By Manual
• Hardware Features
• Alarm Input1 for tamper, NO/NC
• Relay Output1, NO/NC (0~36V DC, Max 5A）
• Serial Port1, for debug
• RF Transmission
• RF Method Two way communication
• RF Modulation2GFSK
• RF Frequency433MHz
• RF Distance800m
• Wireless SecurityAES-128
• Electrical Characteristics
• Power Supply DC 7V – 24V
• Display
• LEDs Status3, Register/Signal (Green/Red), Power (Green), Relay Status (Blue)
• General
• Operation Temperature﹣10℃~+55℃
• Operation Humidity10％~90％
• Shell Material Plastic
• Dimension(WxHxD)38x25x18mm
• 28.5g
• Color White
• Installation Method Wall Mounting
