osch CP156B weather resistant slimline code pad provides alarm and access control functionality when used with the Solution 6000 control panel.

Model : CP156B

The CP156B keypad provides alarm and or access control functionality when used on selected Solution security control panels.

Features :

• Indoor and outdoor use
• Weather and Vandal Resistant with IP67 rating
• Chrome Plated Zinc Die-Cast Finish
• Backlit with Blue led light
• Buy genuine buy from CTC Communications. See attached pdf for more information
• Programmable egress input and lock output
• LED indicator to show alarm stature
• Reporting and logs
• Encrypted LAN communication with Bosch solution 6000 panel

It is fitted with built in smart prox reader, front and rear tamper. Constructed from high strength zinc alloy die cast housing, the CP156B keypad provides a high level of durability and is also weather resistant to IP65 making it ideal for external installations.

The CP156B includes red, green and blue indicators which are used to show area or door lock status. Backlit buttons make it easy to operate in all lighting conditions.

The keypad connects to the control panel via the RS485 encrypted LAN and occupies a standard keypad position in the panel configuration. Various keypad options can be configured via the Devices - Keypad & Readers menu in panel programming. User access events are stored in the panel log and can also be reported if required.

Specifications

• Part Number : CP156B - External 6x2 Metal Keypad With Smart Card Reader (IP67).
• Operating Voltage: 10.0V D.C. - 14.5V D.C. @ 100mA Max.
• Module Connection: (RS485 LAN) Max total LAN length using multi strand security cable = 500m. Max total LAN length using 2 pair twisted shielded data cable (Belden 8723) = 1200m. See the control panel manual for complete wiring instructions.
• Lock Output: Relay 2Amp DC
• Egress Input: Low to trigger. Can be disabled via software control.
• Dimensions: 45mm(W), 23mm(D), 162mm(H). CM444B = 46mm(W), 12.5mm(D), 12mm H)
• Environment: -30 to 55C RH 5 to 85% at 30C non-condensing.
• Fixing Method: The CP156B should be mounted on a sturdy vertical wall using fixtures appropriate for the wall construction type.



Optional for Bosch Solution 6000 Alarm Systems

Connect to the MyAlarm cloud security service to make use of the iFob Control app available on both IOS and Android OS. Check system status, arm or disarm, and operate doors and outputs. You’ll never miss an alarm event with push, voice, SMS or email notification available. You will know when other users have armed or disarmed the system – like your children coming home, or your staff locking up when leaving.
